In this tutorial, we implement a reinforcement learning agent using RLax, a research-oriented library developed by Google DeepMind for building reinforcement learning algorithms with JAX. We combine RLax with JAX, Haiku, and Optax to construct a Deep Q-Learning (DQN) agent that learns to solve the CartPole environment. Instead of using a fully packaged RL framework, we assemble the training pipeline ourselves so we can clearly understand how the core components of reinforcement learning interact. We define the neural network, build a replay buffer, compute temporal difference errors with RLax, and train the agent using gradient-based optimization. Also, we focus on understanding how RLax provides reusable RL primitives that can be integrated into custom reinforcement learning pipelines. We use JAX for efficient numerical computation, Haiku for neural network modeling, and Optax for optimization.
import os
os.environ[“XLA_PYTHON_CLIENT_PREALLOCATE”] = “false”
import random
import time
from dataclasses import dataclass
from collections import deque
import gymnasium as gym
import haiku as hk
import jax
import jax.numpy as jnp
import matplotlib.pyplot as plt
import numpy as np
import optax
import rlax
seed = 42
random.seed(seed)
np.random.seed(seed)
env = gym.make(“CartPole-v1”)
eval_env = gym.make(“CartPole-v1”)
obs_dim = env.observation_space.shape[0]
num_actions = env.action_space.n
def q_network(x):
mlp = hk.Sequential([
hk.Linear(128), jax.nn.relu,
hk.Linear(128), jax.nn.relu,
hk.Linear(num_actions),
])
return mlp(x)
q_net = hk.without_apply_rng(hk.transform(q_network))
dummy_obs = jnp.zeros((1, obs_dim), dtype=jnp.float32)
rng = jax.random.PRNGKey(seed)
params = q_net.init(rng, dummy_obs)
target_params = params
optimizer = optax.chain(
optax.clip_by_global_norm(10.0),
optax.adam(3e-4),
)
opt_state = optimizer.init(params)
We install the required libraries and import all the modules needed for the reinforcement learning pipeline. We initialize the environment, define the neural network architecture using Haiku, and set up the Q-network that predicts action values. We also initialize the network and target network parameters, as well as the optimizer to be used during training.
class Transition:
obs: np.ndarray
action: int
reward: float
discount: float
next_obs: np.ndarray
done: float
class ReplayBuffer:
def __init__(self, capacity):
self.buffer = deque(maxlen=capacity)
def add(self, *args):
self.buffer.append(Transition(*args))
def sample(self, batch_size):
batch = random.sample(self.buffer, batch_size)
obs = np.stack([t.obs for t in batch]).astype(np.float32)
action = np.array([t.action for t in batch], dtype=np.int32)
reward = np.array([t.reward for t in batch], dtype=np.float32)
discount = np.array([t.discount for t in batch], dtype=np.float32)
next_obs = np.stack([t.next_obs for t in batch]).astype(np.float32)
done = np.array([t.done for t in batch], dtype=np.float32)
return {
“obs”: obs,
“action”: action,
“reward”: reward,
“discount”: discount,
“next_obs”: next_obs,
“done”: done,
}
def __len__(self):
return len(self.buffer)
replay = ReplayBuffer(capacity=50000)
def epsilon_by_frame(frame_idx, eps_start=1.0, eps_end=0.05, decay_frames=20000):
mix = min(frame_idx / decay_frames, 1.0)
return eps_start + mix * (eps_end – eps_start)
def select_action(params, obs, epsilon):
if random.random() < epsilon:
return env.action_space.sample()
q_values = q_net.apply(params, obs[None, :])
return int(jnp.argmax(q_values[0]))
We define the transition structure and implement a replay buffer to store past experiences from the environment. We create functions to add transitions and sample mini-batches that will later be used to train the agent. We also implement the epsilon-greedy exploration strategy.
def soft_update(target_params, online_params, tau):
return jax.tree_util.tree_map(lambda t, s: (1.0 – tau) * t + tau * s, target_params, online_params)
def batch_td_errors(params, target_params, batch):
q_tm1 = q_net.apply(params, batch[“obs”])
q_t = q_net.apply(target_params, batch[“next_obs”])
td_errors = jax.vmap(
lambda q1, a, r, d, q2: rlax.q_learning(q1, a, r, d, q2)
)(q_tm1, batch[“action”], batch[“reward”], batch[“discount”], q_t)
return td_errors
@jax.jit
def train_step(params, target_params, opt_state, batch):
def loss_fn(p):
td_errors = batch_td_errors(p, target_params, batch)
loss = jnp.mean(rlax.huber_loss(td_errors, delta=1.0))
metrics = {
“loss”: loss,
“td_abs_mean”: jnp.mean(jnp.abs(td_errors)),
“q_mean”: jnp.mean(q_net.apply(p, batch[“obs”])),
}
return loss, metrics
(loss, metrics), grads = jax.value_and_grad(loss_fn, has_aux=True)(params)
updates, opt_state = optimizer.update(grads, opt_state, params)
params = optax.apply_updates(params, updates)
return params, opt_state, metrics
We define the core learning functions used during training. We compute temporal difference errors using RLax’s Q-learning primitive and calculate the loss using the Huber loss function. We then implement the training step that computes gradients, applies optimizer updates, and returns training metrics.
returns = []
for ep in range(episodes):
obs, _ = eval_env.reset(seed=seed + 1000 + ep)
done = False
truncated = False
total_reward = 0.0
while not (done or truncated):
q_values = q_net.apply(params, obs[None, :])
action = int(jnp.argmax(q_values[0]))
next_obs, reward, done, truncated, _ = eval_env.step(action)
total_reward += reward
obs = next_obs
returns.append(total_reward)
return float(np.mean(returns))
num_frames = 40000
batch_size = 128
warmup_steps = 1000
train_every = 4
eval_every = 2000
gamma = 0.99
tau = 0.01
max_grad_updates_per_step = 1
obs, _ = env.reset(seed=seed)
episode_return = 0.0
episode_returns = []
eval_returns = []
losses = []
td_means = []
q_means = []
eval_steps = []
start_time = time.time()
We define the evaluation function that measures the agent’s performance. We configure the training hyperparameters, including the number of frames, batch size, discount factor, and target network update rate. We also initialize variables that track training statistics, including episode returns, losses, and evaluation metrics.
epsilon = epsilon_by_frame(frame_idx)
action = select_action(params, obs.astype(np.float32), epsilon)
next_obs, reward, done, truncated, _ = env.step(action)
terminal = done or truncated
discount = 0.0 if terminal else gamma
replay.add(
obs.astype(np.float32),
action,
float(reward),
float(discount),
next_obs.astype(np.float32),
float(terminal),
)
obs = next_obs
episode_return += reward
if terminal:
episode_returns.append(episode_return)
obs, _ = env.reset()
episode_return = 0.0
if len(replay) >= warmup_steps and frame_idx % train_every == 0:
for _ in range(max_grad_updates_per_step):
batch_np = replay.sample(batch_size)
batch = {k: jnp.asarray(v) for k, v in batch_np.items()}
params, opt_state, metrics = train_step(params, target_params, opt_state, batch)
target_params = soft_update(target_params, params, tau)
losses.append(float(metrics[“loss”]))
td_means.append(float(metrics[“td_abs_mean”]))
q_means.append(float(metrics[“q_mean”]))
if frame_idx % eval_every == 0:
avg_eval_return = evaluate_agent(params, episodes=5)
eval_returns.append(avg_eval_return)
eval_steps.append(frame_idx)
recent_train = np.mean(episode_returns[-10:]) if episode_returns else 0.0
recent_loss = np.mean(losses[-100:]) if losses else 0.0
print(
f”step={frame_idx:6d} | epsilon={epsilon:.3f} | ”
f”recent_train_return={recent_train:7.2f} | ”
f”eval_return={avg_eval_return:7.2f} | ”
f”recent_loss={recent_loss:.5f} | buffer={len(replay)}”
)
elapsed = time.time() – start_time
final_eval = evaluate_agent(params, episodes=10)
print(“\nTraining complete”)
print(f”Elapsed time: {elapsed:.1f} seconds”)
print(f”Final 10-episode evaluation return: {final_eval:.2f}”)
plt.figure(figsize=(14, 4))
plt.subplot(1, 3, 1)
plt.plot(episode_returns)
plt.title(“Training Episode Returns”)
plt.xlabel(“Episode”)
plt.ylabel(“Return”)
plt.subplot(1, 3, 2)
plt.plot(eval_steps, eval_returns)
plt.title(“Evaluation Returns”)
plt.xlabel(“Environment Steps”)
plt.ylabel(“Avg Return”)
plt.subplot(1, 3, 3)
plt.plot(losses, label=”Loss”)
plt.plot(td_means, label=”|TD Error| Mean”)
plt.title(“Optimization Metrics”)
plt.xlabel(“Gradient Updates”)
plt.legend()
plt.tight_layout()
plt.show()
obs, _ = eval_env.reset(seed=999)
frames = []
done = False
truncated = False
total_reward = 0.0
render_env = gym.make(“CartPole-v1″, render_mode=”rgb_array”)
obs, _ = render_env.reset(seed=999)
while not (done or truncated):
frame = render_env.render()
frames.append(frame)
q_values = q_net.apply(params, obs[None, :])
action = int(jnp.argmax(q_values[0]))
obs, reward, done, truncated, _ = render_env.step(action)
total_reward += reward
render_env.close()
print(f”Demo episode return: {total_reward:.2f}”)
try:
import matplotlib.animation as animation
from IPython.display import HTML, display
fig = plt.figure(figsize=(6, 4))
patch = plt.imshow(frames[0])
plt.axis(“off”)
def animate(i):
patch.set_data(frames[i])
return (patch,)
anim = animation.FuncAnimation(fig, animate, frames=len(frames), interval=30, blit=True)
display(HTML(anim.to_jshtml()))
plt.close(fig)
except Exception as e:
print(“Animation display skipped:”, e)
We run the full reinforcement learning training loop. We periodically update the network parameters, evaluate the agent’s performance, and record metrics for visualization. Also, we plot the training results and render a demonstration episode to observe how the trained agent behaves.
In conclusion, we built a complete Deep Q-Learning agent by combining RLax with the modern JAX-based machine learning ecosystem. We designed a neural network to estimate action values, implement experience replay to stabilize learning, and compute TD errors using RLax’s Q-learning primitive. During training, we updated the network parameters using gradient-based optimization and periodically evaluated the agent to track performance improvements. Also, we saw how RLax enables a modular approach to reinforcement learning by providing reusable algorithmic components rather than full algorithms. This flexibility allows us to easily experiment with different architectures, learning rules, and optimization strategies. By extending this foundation, we can build more advanced agents, such as Double DQN, distributional reinforcement learning models, and actor–critic methods, using the same RLax primitives.
