In this tutorial, we build an advanced Tree-of-Thoughts (ToT) multi-branch reasoning agent from scratch. Instead of relying on linear chain-of-thought reasoning, we design a system that generates multiple reasoning branches, scores each branch using a heuristic evaluation function, prunes weak candidates, and continues expanding only the strongest paths. We combine an instruction-tuned transformer model with a custom tree structure and implement beam-search style selection with depth-limited search. By grounding the system in the 24-game domain, we create a clear, objective benchmark for reasoning where we can observe branch expansion, pruning, scoring, and goal detection in action.
import re
import math
from dataclasses import dataclass, field
from typing import List, Optional, Tuple, Dict, Any
import torch
from transformers import AutoTokenizer, AutoModelForSeq2SeqLM
MODEL_NAME = “google/flan-t5-base”
tokenizer = AutoTokenizer.from_pretrained(MODEL_NAME)
model = AutoModelForSeq2SeqLM.from_pretrained(MODEL_NAME)
device = “cuda” if torch.cuda.is_available() else “cpu”
model = model.to(device)
print(“Device:”, device)
print(“Model loaded:”, MODEL_NAME)
@dataclass
class Node:
depth: int
numbers: List[float]
exprs: List[str]
thought: str = “”
score: float = -1e9
is_goal: bool = False
parent: Optional[“Node”] = None
meta: Dict[str, Any] = field(default_factory=dict)
def pretty_state(nums: List[float], exprs: List[str]) -> str:
pairs = [f”{e}={n:g}” for e, n in zip(exprs, nums)]
return ” | “.join(pairs)
We install the required libraries and load the FLAN-T5 model using the correct Seq2Seq architecture. We define our core Node data structure that represents each reasoning state in the Tree-of-Thoughts search. We also initialize the device configuration and helper utilities that enable us to clearly print and inspect the reasoning state.
def safe_apply(a: float, b: float, op: str) -> Optional[float]:
if op == “+”: return a + b
if op == “-“: return a – b
if op == “*”: return a * b
if op == “/”:
if abs(b) < 1e-12:
return None
return a / b
return None
def combine_expr(ea: str, eb: str, op: str) -> str:
return f”({ea} {op} {eb})”
def is_24(x: float, tol: float = 1e-6) -> bool:
return abs(x – 24.0) <= tol
def one_step_closeness(nums: List[float]) -> float:
if len(nums) == 1:
return abs(nums[0] – 24.0)
best = float(“inf”)
n = len(nums)
for i in range(n):
for j in range(n):
if i == j:
continue
a, b = nums[i], nums[j]
for op in OPS:
r = safe_apply(a, b, op)
if r is None:
continue
best = min(best, abs(r – 24.0))
return best if best != float(“inf”) else 1e9
def heuristic_score(node: Node) -> float:
nums = node.numbers
base = -one_step_closeness(nums)
depth_penalty = 0.05 * node.depth
exact_bonus = 2.0 if any(is_24(x) for x in nums) else 0.0
return base – depth_penalty + exact_bonus
We implement the mathematical logic of the 24-game domain. We define safe operator execution, expression construction, goal checking, and a heuristic scoring function that estimates how close a state is to the goal of 24. We design the heuristic to guide the search intelligently while penalizing deeper branches.
We have current items, each item has an expression and its numeric value.
Pick TWO items and combine them with one operation from + – * / to create a new item.
Return between {k} and {k2} suggestions as lines using EXACT format:
i,j,op
Where i and j are 0-based indices into the list. Use i != j. Prefer moves that help reach 24.
Current items:
{items}
“””
def llm_generate_suggestions(items: str, k_min: int, k_max: int, max_new_tokens: int = 160) -> str:
prompt = PROPOSER_PROMPT.format(k=k_min, k2=k_max, items=items)
inputs = tokenizer(prompt, return_tensors=”pt”, truncation=True).to(device)
with torch.no_grad():
out = model.generate(
**inputs,
max_new_tokens=max_new_tokens,
do_sample=True,
temperature=0.8,
top_p=0.92,
num_return_sequences=1,
)
txt = tokenizer.decode(out[0], skip_special_tokens=True)
return txt.strip()
def parse_moves(text: str, n_items: int) -> List[Tuple[int, int, str]]:
moves = []
for line in text.splitlines():
line = line.strip()
m = re.match(r”^\s*(\d+)\s*,\s*(\d+)\s*,\s*([\+\-\*\/])\s*$”, line)
if not m:
continue
i, j, op = int(m.group(1)), int(m.group(2)), m.group(3)
if 0 <= i < n_items and 0 <= j < n_items and i != j:
moves.append((i, j, op))
seen = set()
uniq = []
for mv in moves:
if mv not in seen:
uniq.append(mv)
seen.add(mv)
return uniq
def fallback_moves(nums: List[float], limit: int = 24) -> List[Tuple[int, int, str]]:
scored = []
n = len(nums)
for i in range(n):
for j in range(n):
if i == j:
continue
for op in OPS:
r = safe_apply(nums[i], nums[j], op)
if r is None:
continue
scored.append((abs(r – 24.0), i, j, op))
scored.sort(key=lambda x: x[0])
out = [(i, j, op) for _, i, j, op in scored[:limit]]
seen, uniq = set(), []
for mv in out:
if mv not in seen:
uniq.append(mv)
seen.add(mv)
return uniq
We build the LLM proposer that generates multiple reasoning branches. We format the prompt carefully so the model returns structured combine operations and parse those outputs into executable moves. We also implement a deterministic fallback strategy to ensure the search remains robust even if the model output is noisy.
nums = node.numbers[:]
exprs = node.exprs[:]
a, b = nums[i], nums[j]
r = safe_apply(a, b, op)
if r is None:
return None
ea, eb = exprs[i], exprs[j]
new_expr = combine_expr(ea, eb, op)
for idx in sorted([i, j], reverse=True):
nums.pop(idx)
exprs.pop(idx)
nums.append(r)
exprs.append(new_expr)
child = Node(
depth=node.depth + 1,
numbers=nums,
exprs=exprs,
parent=node,
thought=f”Combine item {i} and {j} with ‘{op}’ -> {new_expr} = {r:g}”,
)
child.is_goal = (len(nums) == 1 and is_24(nums[0]))
child.score = heuristic_score(child)
return child
def expand(node: Node, branch_factor: int, proposer_kmin: int = 8, proposer_kmax: int = 14) -> List[Node]:
items_str = “\n”.join([f”{idx}: {node.exprs[idx]} = {node.numbers[idx]:g}” for idx in range(len(node.numbers))])
raw = llm_generate_suggestions(items_str, proposer_kmin, proposer_kmax)
moves = parse_moves(raw, len(node.numbers))
if not moves:
moves = fallback_moves(node.numbers, limit=30)
moves = moves[: max(branch_factor * 2, branch_factor)]
children = []
for (i, j, op) in moves:
ch = apply_move(node, i, j, op)
if ch is not None:
children.append(ch)
children.sort(key=lambda x: x.score, reverse=True)
return children[:branch_factor]
We implement the branch expansion mechanism of the Tree-of-Thoughts algorithm. We apply proposed moves to create new child nodes and compute their heuristic scores. We then locally prune weaker branches, retaining only the strongest candidates for further exploration.
path = []
cur = goal
while cur is not None:
if cur.thought:
path.append(cur.thought)
cur = cur.parent
return list(reversed(path))
def tot_solve_24(
start_nums: List[int],
beam_width: int = 10,
branch_factor: int = 8,
max_depth: int = 3,
prune_threshold: float = -10.0,
verbose: bool = True
) -> Dict[str, Any]:
root = Node(
depth=0,
numbers=[float(x) for x in start_nums],
exprs=[str(x) for x in start_nums],
)
root.score = heuristic_score(root)
beam = [root]
best_seen = root
if verbose:
print(“\n=== ToT Search Start ===”)
print(“Start:”, pretty_state(root.numbers, root.exprs))
print(“Root score:”, root.score)
for d in range(max_depth):
candidates: List[Node] = []
if verbose:
print(f”\n— Depth {d} -> {d+1} expansion —“)
print(“Beam states:”)
for bidx, b in enumerate(beam[: min(len(beam), 6)]):
print(f” [{bidx}] score={b.score:.3f} | {pretty_state(b.numbers, b.exprs)}”)
for b in beam:
kids = expand(b, branch_factor=branch_factor)
candidates.extend(kids)
if not candidates:
break
candidates = [c for c in candidates if c.score >= prune_threshold]
goals = [c for c in candidates if c.is_goal]
if goals:
goals.sort(key=lambda x: x.score, reverse=True)
sol = goals[0]
steps = reconstruct_solution(sol)
return {
“solved”: True,
“start”: start_nums,
“expression”: sol.exprs[0],
“value”: sol.numbers[0],
“steps”: steps,
“final_score”: sol.score
}
candidates.sort(key=lambda x: x.score, reverse=True)
beam = candidates[:beam_width]
if beam and beam[0].score > best_seen.score:
best_seen = beam[0]
if verbose:
print(“Top candidates after pruning/beam:”)
for cidx, c in enumerate(beam[: min(len(beam), 6)]):
print(f” [{cidx}] score={c.score:.3f} | {pretty_state(c.numbers, c.exprs)}”)
best_expr = best_seen.exprs[0] if len(best_seen.exprs) == 1 else ” ; “.join(best_seen.exprs)
best_val = best_seen.numbers[0] if len(best_seen.numbers) == 1 else None
return {
“solved”: False,
“start”: start_nums,
“best_state”: pretty_state(best_seen.numbers, best_seen.exprs),
“best_expression”: best_expr,
“best_value”: best_val,
“final_score”: best_seen.score,
“note”: “Not solved within depth/beam limits; increase beam_width/branch_factor or adjust pruning.”
}
tests = [
[4, 1, 8, 7],
[3, 3, 8, 8],
[6, 6, 6, 6],
[9, 9, 4, 4],
]
for nums in tests:
result = tot_solve_24(
nums,
beam_width=12,
branch_factor=10,
max_depth=3,
prune_threshold=-12.0,
verbose=True
)
print(“\n=== RESULT ===”)
for k, v in result.items():
if k == “steps”:
print(“steps:”)
for s in v:
print(” -“, s)
else:
print(f”{k}: {v}”)
print(“\n” + “=”*80 + “\n”)
print(“””
To adapt this ToT agent beyond the 24 game:
1) Define a STATE representation (like numbers/exprs here).
2) Define a PROPOSER that generates candidate next steps (LLM tool or rule-based).
3) Define a HEURISTIC / SCORER:
– for checkable tasks, use objective scoring
– for open-ended tasks, use an LLM-critic scoring rubric
4) Run the same ToT loop:
expand -> score -> prune -> keep top beam -> repeat until goal or depth limit.
“””)
We implement the full Tree-of-Thoughts search loop using beam search and depth limits. We expand, score, prune, and select the top branches at each depth until we either reach a solution or exhaust the search budget. Finally, we reconstruct the reasoning path and demonstrate how the agent solves multiple 24-game instances step by step.
In conclusion, we constructed a complete multi-branch reasoning agent that demonstrates how Tree-of-Thoughts transforms LLM reasoning from a single path into a structured search process. We implemented branch generation, heuristic scoring, pruning, beam selection, and depth control in a modular architecture that can easily be adapted to other reasoning problems. Through this tutorial, we saw how combining language models with search algorithms significantly improves structured decision-making. We now have a reusable ToT framework that we can extend to mathematical reasoning, planning tasks, symbolic search, or even LLM-critic-based evaluation systems.
