In this tutorial, we build an end-to-end cognitive complexity analysis workflow using complexipy. We start by measuring complexity directly from raw code strings, then scale the same analysis to individual files and an entire project directory. Along the way, we generate machine-readable reports, normalize them into structured DataFrames, and visualize complexity distributions to understand how decision depth accumulates across functions. By treating cognitive complexity as a measurable engineering signal, we show how it can be integrated naturally into everyday Python development and quality checks. Check out the FULL CODES here.
import os
import json
import textwrap
import subprocess
from pathlib import Path
import pandas as pd
import matplotlib.pyplot as plt
from complexipy import code_complexity, file_complexity
print(“✅ Installed complexipy and dependencies”)
We set up the environment by installing the required libraries and importing all dependencies needed for analysis and visualization. We ensure the notebook is fully self-contained and ready to run in Google Colab without external setup. It forms the backbone of execution for everything that follows.
def score_orders(orders):
total = 0
for o in orders:
if o.get(“valid”):
if o.get(“priority”):
if o.get(“amount”, 0) > 100:
total += 3
else:
total += 2
else:
if o.get(“amount”, 0) > 100:
total += 2
else:
total += 1
else:
total -= 1
return total
“””
res = code_complexity(snippet)
print(“=== Code string complexity ===”)
print(“Overall complexity:”, res.complexity)
print(“Functions:”)
for f in res.functions:
print(f” – {f.name}: {f.complexity} (lines {f.line_start}-{f.line_end})”)
We begin by analyzing a raw Python code string to understand cognitive complexity at the function level. We directly inspect how nested conditionals and control flow contribute to complexity. It helps us validate the core behavior of complexipy before scaling to real files.
src = root / “src”
tests = root / “tests”
src.mkdir(parents=True, exist_ok=True)
tests.mkdir(parents=True, exist_ok=True)
(src / “__init__.py”).write_text(“”)
(tests / “__init__.py”).write_text(“”)
(src / “simple.py”).write_text(textwrap.dedent(“””
def add(a, b):
return a + b
def safe_div(a, b):
if b == 0:
return None
return a / b
“””).strip() + “\n”)
(src / “legacy_adapter.py”).write_text(textwrap.dedent(“””
def legacy_adapter(x, y):
if x and y:
if x > 0:
if y > 0:
return x + y
else:
return x – y
else:
if y > 0:
return y – x
else:
return -(x + y)
return 0
“””).strip() + “\n”)
(src / “engine.py”).write_text(textwrap.dedent(“””
def route_event(event):
kind = event.get(“kind”)
payload = event.get(“payload”, {})
if kind == “A”:
if payload.get(“x”) and payload.get(“y”):
return _handle_a(payload)
return None
elif kind == “B”:
if payload.get(“flags”):
return _handle_b(payload)
else:
return None
elif kind == “C”:
for item in payload.get(“items”, []):
if item.get(“enabled”):
if item.get(“mode”) == “fast”:
_do_fast(item)
else:
_do_safe(item)
return True
else:
return None
def _handle_a(p):
total = 0
for v in p.get(“vals”, []):
if v > 10:
total += 2
else:
total += 1
return total
def _handle_b(p):
score = 0
for f in p.get(“flags”, []):
if f == “x”:
score += 1
elif f == “y”:
score += 2
else:
score -= 1
return score
def _do_fast(item):
return item.get(“id”)
def _do_safe(item):
if item.get(“id”) is None:
return None
return item.get(“id”)
“””).strip() + “\n”)
(tests / “test_engine.py”).write_text(textwrap.dedent(“””
from src.engine import route_event
def test_route_event_smoke():
assert route_event({“kind”: “A”, “payload”: {“x”: 1, “y”: 2, “vals”: [1, 20]}}) == 3
“””).strip() + “\n”)
print(f”✅ Created project at: {root.resolve()}”)
We programmatically construct a small but realistic Python project with multiple modules and test files. We intentionally include varied control-flow patterns to create meaningful differences in complexity. Check out the FULL CODES here.
file_res = file_complexity(str(engine_path))
print(“\n=== File complexity (Python API) ===”)
print(“Path:”, file_res.path)
print(“File complexity:”, file_res.complexity)
for f in file_res.functions:
print(f” – {f.name}: {f.complexity} (lines {f.line_start}-{f.line_end})”)
MAX_ALLOWED = 8
def run_complexipy_cli(project_dir: Path, max_allowed: int = 8):
cmd = [
“complexipy”,
“.”,
“–max-complexity-allowed”, str(max_allowed),
“–output-json”,
“–output-csv”,
]
proc = subprocess.run(cmd, cwd=str(project_dir), capture_output=True, text=True)
preferred_csv = project_dir / “complexipy.csv”
preferred_json = project_dir / “complexipy.json”
csv_candidates = []
json_candidates = []
if preferred_csv.exists():
csv_candidates.append(preferred_csv)
if preferred_json.exists():
json_candidates.append(preferred_json)
csv_candidates += list(project_dir.glob(“*.csv”)) + list(project_dir.glob(“**/*.csv”))
json_candidates += list(project_dir.glob(“*.json”)) + list(project_dir.glob(“**/*.json”))
def uniq(paths):
seen = set()
out = []
for p in paths:
p = p.resolve()
if p not in seen and p.is_file():
seen.add(p)
out.append(p)
return out
csv_candidates = uniq(csv_candidates)
json_candidates = uniq(json_candidates)
def pick_best(paths):
if not paths:
return None
paths = sorted(paths, key=lambda p: p.stat().st_mtime, reverse=True)
return paths[0]
return proc.returncode, pick_best(csv_candidates), pick_best(json_candidates)
rc, csv_report, json_report = run_complexipy_cli(root, MAX_ALLOWED)
We analyze a real source file using the Python API, then run the complexipy CLI on the entire project. We run the CLI from the correct working directory to reliably generate reports. This step bridges local API usage with production-style static analysis workflows.
if csv_report and csv_report.exists():
df = pd.read_csv(csv_report)
elif json_report and json_report.exists():
data = json.loads(json_report.read_text())
if isinstance(data, list):
df = pd.DataFrame(data)
elif isinstance(data, dict):
if “files” in data and isinstance(data[“files”], list):
df = pd.DataFrame(data[“files”])
elif “results” in data and isinstance(data[“results”], list):
df = pd.DataFrame(data[“results”])
else:
df = pd.json_normalize(data)
if df is None:
raise RuntimeError(“No report produced”)
def explode_functions_table(df_in):
if “functions” in df_in.columns:
tmp = df_in.explode(“functions”, ignore_index=True)
if tmp[“functions”].notna().any() and isinstance(tmp[“functions”].dropna().iloc[0], dict):
fn = pd.json_normalize(tmp[“functions”])
base = tmp.drop(columns=[“functions”])
return pd.concat([base.reset_index(drop=True), fn.reset_index(drop=True)], axis=1)
return tmp
return df_in
fn_df = explode_functions_table(df)
col_map = {}
for c in fn_df.columns:
lc = c.lower()
if lc in (“path”, “file”, “filename”, “module”):
col_map[c] = “path”
if (“function” in lc and “name” in lc) or lc in (“function”, “func”, “function_name”):
col_map[c] = “function”
if lc == “name” and “function” not in fn_df.columns:
col_map[c] = “function”
if “complexity” in lc and “allowed” not in lc and “max” not in lc:
col_map[c] = “complexity”
if lc in (“line_start”, “linestart”, “start_line”, “startline”):
col_map[c] = “line_start”
if lc in (“line_end”, “lineend”, “end_line”, “endline”):
col_map[c] = “line_end”
fn_df = fn_df.rename(columns=col_map)
We load the generated complexity reports into pandas and normalize them into a function-level table. We handle multiple possible report schemas to keep the workflow robust. This structured representation allows us to reason about complexity using standard data analysis tools.
fn_df[“complexity”] = pd.to_numeric(fn_df[“complexity”], errors=”coerce”)
plt.figure()
fn_df[“complexity”].dropna().plot(kind=”hist”, bins=20)
plt.title(“Cognitive Complexity Distribution (functions)”)
plt.xlabel(“complexity”)
plt.ylabel(“count”)
plt.show()
def refactor_hints(complexity):
if complexity >= 20:
return [
“Split into smaller pure functions”,
“Replace deep nesting with guard clauses”,
“Extract complex boolean predicates”
]
if complexity >= 12:
return [
“Extract inner logic into helpers”,
“Flatten conditionals”,
“Use dispatch tables”
]
if complexity >= 8:
return [
“Reduce nesting”,
“Early returns”
]
return [“Acceptable complexity”]
if “complexity” in fn_df.columns and “function” in fn_df.columns:
for _, r in fn_df.sort_values(“complexity”, ascending=False).head(8).iterrows():
cx = float(r[“complexity”]) if pd.notna(r[“complexity”]) else None
if cx is None:
continue
print(r[“function”], cx, refactor_hints(cx))
print(“✅ Tutorial complete.”)
We visualize the distribution of cognitive complexity and derive refactoring guidance from numeric thresholds. We translate abstract complexity scores into concrete engineering actions. It closes the loop by connecting measurement directly to maintainability decisions.
In conclusion, we presented a practical, reproducible pipeline for auditing cognitive complexity in Python projects using complexipy. We demonstrated how we can move from ad hoc inspection to data-driven reasoning about code structure, identify high-risk functions, and provide actionable refactoring guidance based on quantified thresholds. The workflow allows us to reason about maintainability early, enforce complexity budgets consistently, and evolve codebases with clarity and confidence, rather than relying solely on intuition.
